Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: TEYUAN
  • Model Number: TBE- 232FWc
  • Style: Electronic
  • Usage: PL-C, PL-L, PL-T, CFM, CFQ, CFL
  • Matched Tube: T5 T8 T9
  • Power Factor Compensation: Active
  • Service: OEM Service Offered, Design Service Offered, Buyer Label Offered
  • Warranty: Three years
  • Color: White
  • Power Factor: More than 0.98

Packaging & Delivery

Packaging Details: 1.Regular product packaging: 50pcs/box; N.W.9KG/box, G.W.9.7KG/box 2.Carton box package,Tan five layers, Box Size:350x260x140(LxWxH,mm) 3.2400pcs/pallets, pallet size: 1050*1000*130(L*W*H,mm) 4.24000pcs/20'container,48000pcs/40'container
Delivery Detail: 5-20 days depends on the quantity

Specifications

1.2x26W PLC Electronic Ballast with 120/277V UL Listed
2.High Power Factor,Low THD
3.UL CUL CE
4.3 years warranty

Product Description

Production Name

2x26W PLC Electronic Ballast with 120/277V UL Listed



TEYUAN electronic ballast specifications overviews:

Input Voltage120-277V
Lamp Type

2 lamp 26W PLC

Lamp Number1,2 Lamps
Common Specifications

50/60 Hz
High power factor
Low harmonic distortion
High luminous efficacy
Virtually eliminates lamp flicker
Starting Method: Instant Start/Rapid Start
Sound Rated: A
TYPE 1 Outdoor
Class P
EEI=A2
Ambient Temperature (Ta): -15°C-50°C
Case Temperature (Tc): 75°C
Min. Starting Temp.: -15°C
Over input-current protection circuit
Over input-voltage protection circuit
Abnormal output protection circuit
End of lamp life protection circuit



Technical specfications:

ModelLamp TypeNum.
of Lamps
Input
Voltage
(V)
Input
Current
(Amps)
Input
Power
(Watts)
Power
Factor
Max
THD
%
Min. Start
Temp(°F/°C)
TBE-232FWCFQ/TR 26W1120V/277V0.24/0.1128≥0.98100/-18
TBE-232FWCFQ/TR 26W2120V/277V0.42/0.1950≥0.98100/-18



Physical Characteristics for Model: TBE-232FW:

Overall DimensionsCase
Length(L1)120mmPlastic
Length(L2)105mm
Width(W)64mm
Height(H)29mm
Mounting(M)114mm



Products and details show :



Certifications : UL CUL FCC CE ROHS




Packaging & Shipping
1.Regular product packaging: 20pcs/box,N.W.12KG/box, G.W.12.5KG/box
2.Carton box package,Tan five layers, Box Size:300x255x145(LxWxH,mm)
3.1680pcs/pallets, pallet size: 1050*1000*130(L*W*H,mm)
4.16800pcs/20'container,33600pcs/40'container

Our Services
SampleRegular Sample 3-5 days for delivery
Irregular 5-10 days for delivery
Customized servicesODM
OEM
Develop new products independently as per client's requirement
Warranty3 years no hassle warranty


Company Information



Quality Control:




FAQ



We can make our products to fit various line voltage, frequency, environment and luminaries as per the customer's requests.



Please feel free to contact us if any queries.  Give us a chance, we will give you valuable reward

.
